¡EHIGH STARTING & HIGH TORQUE COMPRESSOR, STABILITY DEVICE
¡EPUMP IN CHAMBER IS STAINLESS STEEL MADE
¡ECAN BE EQUIPPED WITH LOW LIQUID STOP DEVICE
MODEL LW-10 LW-15 LW-22
DIMENSION (WxHxL) 23x15x30cm 32x15x32cm 30x15x50cm
TEMP. RANGE PLEASE SEE THE LIST
TEMP. PRECISION ±0.1
TEMP. SPREAD ±0.3¢J
TEMP. CONTROL PID + SSR + PT100 TEMP. INDUCTION
INTERNAL MATERIAL STAINLESS STEEL SUS304#
EXTERNAL MATERIAL BAKED PAINTED STEEL PLATE
COMPRESSOR STEEL PLATE COMPRESSOR
CIRCULATION STAINLESS STEEL SPRAY TYPE PUMP (TEMP. CIRCULATION SPREAD
UNIFORMLY) OR AS REQUESTED
CHAMBER IN FORMED WITH PATCHING DEVICE
KEEP WARD MATERIAL PU FOAM OR CERAMIC FIBER
POWER 110V or 220v
WATT 1200W 1500W 1800W
ATTACHMENTS FLAT COVER 1 PC
TEMP RANGE LIST
LOW TEMP¡G A=0¢J B= -10¢J C= -20¢J D= -30¢J
¡@ E= -40¢J F= -50¢J G= -60¢J ¡@
HI TEMP¡G R=100¢J T=150¢J H=200¢J ¡@
¡@ IG¡GLW-10CR= -20¢J~100¢J
IG¡GLW-22FT= -50¢J~150¢J
|
